In case you’re a fan of unpolluted & minimalistic PC builds, then NZXT has you lined with its first AMD motherboard, the NZXT N7 B550. The corporate is well-known for its clear and feature-rich PC instances and has been providing Intel motherboards for just a few years now however the N7 B550 marks an official entry for NZXT on the AMD platform.
NZXT’s N7 B550 Motherboard Has All The Options You’d Count on For Your AMD Ryzen PC Construct & Additionally Comes With A Clear & Minimalist Design
The NZXT N7 B550 motherboard is not designed for the flashy RGB gamer aesthetic however as an alternative for extra easy and cleaner PC builds. It’s primarily based across the AMD platform and can assist each the Ryzen 5000 and Ryzen 3000 desktop CPUs. The motherboard is available in two flavors, a Matte White variant and a Matte Black variant. Each fashions value $229.99 US which is a good worth given the design and high quality of the motherboard. Most premium B550 designs do fall within the $200-$250 US worth vary so I feel we are able to say that the pricing is justified right here.
Following are among the highlighted options of the NZXT N7 B550 motherboard earlier than we get into extra technical particulars:
- Designed round AMD’s B550 chipset, the N7 B550 delivers all the pieces it’s good to construct an unbelievable gaming PC.
- Options embrace built-in Wi-Fi 6E connectivity, built-in fan controller, entrance panel USB 3.2 Gen2 Sort-C, RGB equipment supported throughout all producers, and extra.
- The motherboard cowl completely matches the colour and end of your NZXT case, making a visually seamless backdrop to your elements.
- Wi-Fi 6E connectivity with up to date specs for B550 chipset
- Digital RGB lighting management by means of CAM: superior lighting with quite a few presets and customized modes and compatibility throughout the board for all lighting equipment.
- Digital fan management: handy fan profiles inside CAM for seven impartial fan channels
- Built-in rear I/O defend and environment friendly structure ensures simple and optimum setup with straightforward upgradeability
- Suitable with third Gen AMD Ryzen processors (3000, 4000, and 5000 Sequence Processors)
- Two M.2 connectors for storage gadgets
- Intel Wi-Fi 6E wi-fi connectivity and Bluetooth V5.2
- Multi-GPU assist with AMD CrossFireX Expertise
- Helps reminiscence overclocking speeds of as much as 4600+ MHz and XMP
- 8-channel high-definition audio
NZXT N7 B550 (AMD) Motherboard In Matte White:
NZXT N7 B550 (AMD) Motherboard In Matte Black:
The NZXT N7 B550 options the AM4 CPU socket that’s powered by a 14+2 section energy supply. The CPU socket is powered by an 8+4 pin connector configuration. There are 4 DDR4 reminiscence slots on the board which assist as much as 128 GB capacities with speeds of as much as 4600 MHz (OC+). It appears to be like like NZXT is utilizing the identical design method as their Intel-based N7 motherboards with a chic metallic cowl (white or black) that covers the elements. The areas across the PCH and the VRM are perforated with holes in order that air can vent out contemplating that they’ve massive metallic heatsinks beneath them. There is no such thing as a energetic cooling resolution utilized by NZXT however we are able to see a IO plate masking the connectors on the very high.
As for I/O, the NZXT N7 B550 (AMD) motherboard options two PCIe 3.0 slots x16 slots (x16 / x4 electrical). There are additionally two M.2 slots and a single M.2 Key slot which is occupied by a WiFi 6E networking card. The motherboard has the next I/O ports:
| USB Ports | 3 x USB 3.2 Gen 2 ports (3 at again panel) 1 x USB 3.2 Gen 2 Sort-C (at again panel) 1 x USB 3.2 Gen 2 entrance panel port (For USB Sort-C) 8 x USB 3.2 Gen 1 ports (4 at again panel, 4 at mid-board) 8 x USB 2.0 ports (2 at again panel, 6 at mid-board) |
| Rear I/O | 2 x USB 2.0 ports 3 x USB 3.2 Gen 2 port 1 x USB 3.2 Gen 2 Sort-C port 4 x USB 3.2 Gen 1 ports 1 x HDMI™ port 2 x Wi-fi antenna SMA connectors 1 x Clear CMOS button 1 x BIOS Flashback button 1 x LAN (RJ45) port 1 x Optical S/PDIF Out port 1 x 5.1-Channel audio jacks |
| Inner I/O | 1 x 24-pin ATX energy connector 1 x 8+4-pin ATX 12V energy connector 1 x 4-pin CPU_FAN connector(1) 1 x 4-pin AIO_PUMP connector(2) 5 x 4-pin SYS_FAN connectors(2) 2 x NZXT RGB LED connectors(3) 1 x 5V ARGB LED connector(4) 1 x 12V RGB LED connector(5) 3 x USB 2.0 header (As much as 6 USB 2.0 ports) 2 x USB 3.2 Gen1 header (As much as 4 USB 3.2 Gen 1 ports) 1 x USB 3.2 Gen2 entrance panel header (For USB Sort-C) 6 x SATA 6Gb/s connectors 1 x M.2 Socket 3 with M Key, sort 2242/2260/2280 storage machine assist (PCIe 4.0 x4 mode (with Matisse & Vermeer) or PCIe 3.0 x4 (with Renoir)) 1 x M.2 Socket 3 with M Key, sort 2242/2260/2280 storage machine assist (PCIe 3.0 x2 & SATA mode) 1 x M.2 Socket 1 with E Key, (For wi-fi playing cards) 1 x Entrance panel audio connector 1 x Energy button 1 x Reset button 4 x POST LEDs |
You may as well anticipate the complete assist of NZXT CAM by means of the N7 B550 motherboard, permitting you full monitoring and management of the motherboard whereas additionally providing configuration of LED lights if you’re going to go that route even on this motherboard. The motherboard is obtainable for buy at this hyperlink.
